Four scroll progress visualization styles using GSAP ScrollTrigger.
Quick Start
1. Add to your HTML <head>:
<link rel="stylesheet" href="path/to/style.css">
2. Add before closing </body> tag:
<script src="https://cdn.jsdelivr.net/npm/gsap@3.14.2/dist/gsap.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/gsap@3.14.2/dist/ScrollTrigger.min.js"></script>
<script src="path/to/script.js"></script>
3. Add the indicator HTML anywhere in your <body>:
<div class="progress-bar" data-progress-style="bar">
<div class="progress-bar__fill"></div>
</div>
Styles
| Style | Description | Best For |
|---|---|---|
bar |
Horizontal bar at top/bottom | Blog posts, documentation |
circle |
SVG ring with optional percentage | Landing pages, minimal designs |
rail |
Vertical bar on left/right edge | Editorial sites, vertical emphasis |
counter |
Numeric percentage display | Technical docs, data-driven UIs |
Style Markup
Each style requires specific HTML. Add one of these anywhere in your <body>:
Bar
HTML:
<div class="progress-bar" data-progress-style="bar">
<div class="progress-bar__fill"></div>
</div>
Variants: Add progress-bar--bottom for bottom position, progress-bar--thick for 5px height.
Circle
HTML:
<div class="progress-circle" data-progress-style="circle">
<svg class="progress-circle__svg" viewBox="0 0 60 60">
<circle class="progress-circle__bg" cx="30" cy="30" r="25"/>
<circle class="progress-circle__fill" cx="30" cy="30" r="25"/>
</svg>
<span class="progress-circle__text">0%</span>
</div>
Variants: Add position classes:
progress-circle--top-rightprogress-circle--top-leftprogress-circle--bottom-left- Default is bottom-right
Rail
HTML:
<div class="progress-rail progress-rail--right" data-progress-style="rail">
<div class="progress-rail__fill"></div>
</div>
Variants: progress-rail--left or progress-rail--right
Counter
HTML:
<div class="progress-counter" data-progress-style="counter">
<span class="progress-counter__value">0</span>
<span class="progress-counter__symbol">%</span>
</div>
Variants: Add position classes:
progress-counter--top-leftprogress-counter--top-rightprogress-counter--bottom-right- Default is bottom-left
Core Pattern
All styles use the same ScrollTrigger pattern. This is already included in script.js — shown here for reference:
JavaScript:
ScrollTrigger.create({
trigger: document.documentElement,
start: 'top top',
end: 'bottom bottom',
scrub: 0.5,
onUpdate: (self) => {
// self.progress = 0 to 1
updateProgress(self.progress);
}
});
Programmatic Use
The ScrollProgress class is exposed globally. Add this to your own JavaScript file or a <script> tag:
JavaScript:
const element = document.querySelector('.my-progress');
const progress = new ScrollProgress(element, {
style: 'bar' // 'bar', 'circle', 'rail', 'counter'
});
// Cleanup
progress.destroy();
Customization
Add these to your own stylesheet or a <style> tag to override defaults.
Colors
CSS:
:root {
--accent: #ff6b6b; /* Progress fill color */
--border: rgba(255, 255, 255, 0.1); /* Track color */
}
Bar Height
CSS:
.progress-bar {
height: 5px; /* Default is 3px */
}
Circle Size
CSS:
.progress-circle {
width: 80px;
height: 80px;
}
Adjust stroke-dasharray when changing circle radius:
- Formula:
2 * PI * radius - Default (r=25):
157
Rail Width
CSS:
.progress-rail {
width: 6px; /* Default is 4px */
}
Accessibility
- All indicators use
aria-hidden="true"(decorative, not interactive) - Respects
prefers-reduced-motion— shows static 100% state - No keyboard interaction needed (passive visualization)
- Scroll position remains accessible via native browser UI
Browser Support
Modern browsers (ES6+). Not compatible with IE11.
Dependencies
- GSAP 3.12+
- ScrollTrigger plugin
- Lenis (optional — for smooth scrolling; effect works without it)
