Draggable Bottom Sheet

Quick Start

1. Add to your HTML <head>:

Code snippet omitted: it ships with the download.

2. Add before the closing </body> tag:

Code snippet omitted: it ships with the download.

3. Copy the component markup from index.html — the block between <!-- Component starts here --> and <!-- Component ends here -->, plus a trigger button carrying data-sheet-open.

The script finds everything by data attribute, so you can rename classes and ids freely:

What's Included

• index.html: the demo page and the markup to copy

• assets/style.css: component styles, plain CSS custom properties for colours

• assets/script.js: readable, commented source with an onReady guard

• assets/script.min.js: minified production script

• thumbnail.html: build-only capture state

• Three detents — peek, half and full — derived from the sheet's measured height and the height of its header, re-derived by a ResizeObserver when the box changes, so a font load, a rotation or a restyle never leaves them stale

• Release velocity picks the detent: the position is projected 0.16s ahead at the release velocity and the nearest stop wins, so a 50px flick outruns a 300px slow drag, and a hard flick down dismisses

• Scrollable content with a real hand-off: a gesture that starts in the list scrolls the list (with its own momentum throw); only a downward drag begun with the list already at the top takes the sheet

• Backdrop opacity and corner radius follow the live drag position, not the open and close tweens, so both track the finger and both survive a mid-flight reversal

• The second open is never stale: the closed state is a yPercent, the open state is a pixel y, and closing resets one to the other before draggable.update()

• Roles: dialog with aria-modal on the sheet, slider on the handle (aria-valuetext reads Peek, Half or Full), status for announcements, and aria-expanded on the trigger

Using It With Your Own Design

What the component needs from your markup: the data attributes above, a data-sheet-head that is a fixed-height block (the peek detent is measured from it), and a data-sheet-scroll that is the flex child which grows. Everything else — copy, rows, buttons — is yours.

What is only the demo: every .stage-* rule in assets/style.css (the handset screen the sheet opens over, and the .stage-narrow rule that shows the sheet at handset width so it lines up with that column), the toolbar strip and its inline CSS in index.html, and the two small inline scripts at the bottom of index.html — the one that fills the sheet from a tapped delivery row, and the one that mirrors the detent buttons. None of it ships with the component; delete all of it, along with the Google Font link if you already load a face.

CSS the component depends on:

• No CSS transform on the sheet, ever. GSAP owns yPercent and Draggable owns y; a translateY(100%) in your stylesheet is read as a pixel offset that no yPercent tween undoes. That is also why the sheet is centred with margin: 0 auto between left: 0 and right: 0 rather than with translateX(-50%).
• touch-action: none on the sheet: Draggable owns the vertical gesture, including inside the list, because the hand-off is decided in JavaScript.
• data-lenis-prevent on data-sheet-scroll. It scrolls vertically only, which is the one case where that attribute is correct; never put it on a horizontal scroller or Lenis stops handling the vertical wheel as well.
• Anything draggable inside the sheet needs draggable="false" and -webkit-user-drag: none (the stylesheet sets it for a and img). Otherwise the browser's native drag starts, the pointer stream is cancelled and the click never lands.
• --radius-live is set on the sheet by the script each frame; keep border-top-*-radius: var(--radius-live, var(--radius-sheet)).
• The footer's padding-bottom includes env(safe-area-inset-bottom), which is what keeps the primary button clear of a notched phone's home indicator. Your page needs viewport-fit=cover in its viewport meta for the inset to be non-zero.

Themes

Two themes, light (the default) and dark: the same design at two sets of token values. Pick one by setting the attribute on <body> in the demo, or on the component's owning root in your page (the ground colour is part of the look):

Code snippet omitted: it ships with the download.

Nothing else changes: same markup, same script. The demo's toggle and the ?variant=dark URL parameter only set that attribute, and the JavaScript never reads it — the radii it animates are read back out of the CSS at use time, and a ResizeObserver re-measures the detents when a switch changes the box.

Every colour, radius, shadow and font is a custom property defined in both body[data-variant="light"] and body[data-variant="dark"] in assets/style.css:

To wear your own brand, re-value those properties in place rather than writing selector overrides — every one of them is read from the block, including both radii, so a rebrand never needs a new rule.

How It Works

Velocity decides, not distance. A tracker samples the pointer position and the clock on every move. On release the sheet's current y is projected 0.16 seconds ahead at that velocity, and whichever stop is nearest the projected point wins — with the dismissed position counted as a stop, so a hard flick throws the sheet off the bottom of the screen. This is the whole difference between a sheet that feels thrown and one that feels dropped.

The scroll hand-off. One Draggable owns the whole sheet, so what a gesture means is decided once, on its first move: a press outside the list, or with the sheet collapsed, moves the sheet; a press inside the list moves the list, unless the list is already at scrollTop: 0 and the drag is downward. In list mode the script writes scrollTop itself from the pointer delta and refuses to render Draggable's y, then throws the list with its own momentum on release. The decision is per gesture, as on iOS: scrolling to the top mid-swipe does not hand the sheet the rest of that swipe, it takes the next one.

The reset that makes the second open right. Closing tweens y to exactly one sheet height, then swaps to yPercent: 100, y: 0 at the moment those two are visually identical and calls draggable.update() so Draggable's own idea of the position matches the element. Without it the sheet reopens wherever the last drag dropped it — the single most common bug in a hand-rolled sheet.

Public API. The first instance is exposed on window:

Code snippet omitted: it ships with the download.

Events. The overlay root dispatches bubbling CustomEvents:

Code snippet omitted: it ships with the download.

source is one of drag, keyboard, trigger, button, backdrop, handle or api, so you can tell a deliberate dismissal from a flick.

Keyboard & Accessibility

• The detent keys are handled on the handle (a role="slider" with aria-valuetext of Peek, Half or Full) and on the header. Inside the list they are deliberately left alone, so arrowing through a radio group still works.
• The sheet is a role="dialog" with aria-modal="true", labelled by its title. Opening moves focus to the handle, closing returns it to whatever opened the sheet, and Tab is trapped inside while it is open. Focus is never left inside the hidden panel, however the sheet was dismissed; a dismissal by drag or backdrop tap only declines to steal focus back from somewhere the user has since moved it.
• The page behind is locked while the sheet is open, with the scrollbar's width compensated so the layout does not shift sideways.
• Detent changes and dismissals are announced through a polite role="status" region.
• Every row, chip and button is at least 40px tall, and coarse pointers get a larger handle and a wider grab area.
• Under prefers-reduced-motion: reduce the sheet moves between the same states with zero duration, and the list's momentum throw is off. The component is never disabled.

Customisation

• Detent positions: geom.peek / geom.half in measure() in assets/script.js — both are fractions of the measured height, so they stay right at any sheet size.
• Feel: PROJECTION (how far a release is projected ahead) and FLICK_DISMISS (the velocity that dismisses outright) at the top of assets/script.js.
• Corner behaviour: --radius-sheet and --radius-sheet-full per theme; the script tweens between them as you drag.
• Colours live in assets/style.css as custom properties per theme (see Themes).
• Easing and durations are the gsap.to calls in assets/script.js.

Requirements

• GSAP 3.12+, plus the Draggable plugin
• No build step, no framework
