Segmented Control

Quick Start

1. Add to your HTML <head>:

Code snippet omitted: it ships with the download.

2. Add before the closing </body> tag:

Code snippet omitted: it ships with the download.

3. Add the component markup:

Copy the block marked <!-- Component starts here --> in index.html. Trimmed to its bones it is:

Code snippet omitted: it ships with the download.

Every element is found by data- attribute, so class names are yours to rename. data-value on the root picks the option selected on load; leave it off and the option with aria-checked="true" wins. Any number of switches can live on one page — each initialises independently.

Mark an option disabled with disabled aria-disabled="true". Drop the <svg> for a label-only option; drop the two seg__edge spans if the strip can never overflow.

Using It With Your Own Design

What the component needs from your markup: the data- attributes above, real <button> elements for the options, and the indicator as the first child of the track. Nothing else about the surrounding page matters.

What is only the demo's styling: everything below the "Demo furniture" comment in assets/style.css (.stage, .stage__inner, .stage-row and its label and hint) plus the toolbar strip, the "Simulate save" button and the theme toggle in index.html, and the Google Font link. The three labelled rows are there so a single control reads as a setting rather than as a lone bar on a blank page; none of it is part of what you bought. Delete all of it; the switch is display: block and sits wherever you put it.

CSS the component depends on:

• The indicator keeps left: 0. Its whole offset is the measured x. A CSS left on top of it doubles the offset.
• No CSS transform on .seg__indicator or .seg__icon — GSAP owns those, and a CSS transform underneath one is read as a pixel offset it never returns from.
• .seg__track must stay position: relative and width: max-content (the indicator is positioned against it, and options must be free to overflow rather than squash).
• .seg__scroller carries the bar's background, border and radius, and hides its own scrollbar.
• No data-lenis-prevent on the scroller. It scrolls horizontally only, and that attribute would silently take Lenis off the page's vertical wheel as well.

What's Included

• index.html: the demo — three switches as labelled settings rows, one of them with icons
• assets/style.css: component CSS, both themes, and the demo furniture (clearly marked)
• assets/script.js: readable GSAP core source with the keyboard model, public API and cleanup
• assets/script.min.js: minified production script
• thumbnail.html: build-only capture state

Themes

Two themes, one design: light (the default) and dark. Set the attribute on the component's owning root in a product page, or on <body> in the demo:

Code snippet omitted: it ships with the download.

Same markup, same script. The demo's toolbar toggle and the ?variant=dark URL parameter only set that attribute; neither is part of the component.

Each body[data-variant="…"] block in assets/style.css holds two short lists. The first is the ground a buyer re-values for their own brand:

--ground, --ground-2, --raised, --hover, --ink, --ink-2, --ink-3, --line, --line-strong, --accent, --accent-ink, --accent-wash, --shadow, --font, --radius, --radius-sm, --radius-xs

The second is the component, written in terms of the first, so in most cases you change nothing here at all: --bar-bg, --bar-border, --bar-radius, --bar-pad, --bar-shadow, --edge-bg, --ind-bg, --ind-top, --ind-height, --ind-radius, --ind-shadow, --ind-progress, --btn-fg, --btn-active-fg, --btn-hover-bg, --btn-off-fg, --btn-weight, --focus-ring.

Because the indicator's own geometry is in that list, a different look never needs a selector override: set --ind-top: calc(100% - 3px) and --ind-height: 3px and the pill becomes an underline while the script still tweens the same x, width and scaleX. The JavaScript never reads the theme name; where it needs a theme-dependent value it reads a custom property at use time.

A theme change can alter fonts and padding, so dispatch a resize (or call refresh()) after switching — the demo does this in its toggle.

How It Works

Distance drives the deformation. Each change compares the target x with the one the indicator is holding. That distance, as a fraction of the strip, sets how far the pill stretches, how long the tween runs, and which edge the stretch is anchored to (the leading edge, so the body smears behind it). A neighbouring hop is almost rigid; a jump across four options smears, then settles on elastic.out(1, 0.75).

The label follows the pill, not the click. The is-on class is reassigned every frame to whichever option the indicator's centre is nearest, so a long jump lights each option it crosses. aria-checked moves on the click instead, so assistive technology hears the new state immediately.

Measured against the track, not the viewport. Option rects are read relative to the track, which shifts with the scroll exactly as they do — so scrolling never corrupts the measurement. Geometry is re-read on resize, on document.fonts.ready, and whenever you call refresh().

Busy without losing the position. setBusy holds the indicator where it is, marks the option aria-busy and loops a gradient sweep inside the pill until you resolve it. Selecting a different option cancels it, so a slow request can never leave the control lying about what is selected.

Public API

The instances are exposed for wiring; window.segmentedSwitch is the first one on the page, window.segmentedSwitches is all of them in document order.

Code snippet omitted: it ships with the download.

Events

The root dispatches three bubbling CustomEvents:

Code snippet omitted: it ships with the download.

Accessibility

• The track is a role="radiogroup" and each option a role="radio" with aria-checked. Label the group with aria-label or aria-labelledby.
• Roving tabindex: the group is one stop in the tab order. Left/Right and Up/Down move to the previous or next enabled option and select it (the standard radiogroup model), Home and End jump to the first and last enabled option, Enter and Space select the focused one.
• Disabled options are skipped by the arrow keys, are not focusable, and cannot be clicked.
• Selection and the start of a busy state are announced through a polite role="status" region; a busy option is also marked aria-busy="true".
• Focus is visible on every option through :focus-visible, inset so the ring is never clipped by the bar.
• Coarse pointers get 44px-high targets, momentum scrolling on the strip, and no hover-only state.
• Under prefers-reduced-motion: reduce the indicator jumps rather than springs, the strip scrolls instantly, the icon pop is off, and the busy sweep is a static bar.
• With JavaScript off there is no indicator at all: the checked option carries its own underline, so the control still reads correctly.

Customisation

• Colours, radii and the indicator geometry live in assets/style.css as custom properties per theme.
• STRETCH_MAX at the top of assets/script.js is how far the pill may stretch on a full-width jump (0.42 = 42% of its own width). SCROLL_PAD is the gap kept between the selected option and the edge of the strip.
• The settle is the elastic.out(1, 0.75) in applyIndicator; the duration ramps with distance in the same function.

Requirements

• GSAP 3.12+ (the demo uses 3.15.0; core only)
• No build step, no framework
