Animated Modal Dialog

What's Included

• index.html: the demo page and the markup to copy

• assets/style.css: component styles, every colour a CSS custom property

• assets/script.js: readable, commented source with an onReady guard

• assets/script.min.js: minified production script

• Flip morph from any trigger's box into the dialog, tweening width, height, corner radius and background colour rather than scale, so the type inside stays upright for the whole tween

• The close morph measures the trigger at close time, so it lands back on the right button however far the page has been scrolled

• Three placements from one attribute (data-modal-mode): center, drawer, sheet — same markup, same script, and a drawer becomes a bottom sheet under 560px

• Several triggers on a page, each morphing to and from its own dialog, and a second open that re-measures rather than replaying the first (the demo shows one trigger and one dialog)

• A stack: a dialog can open over another, the one behind recedes and leaves the tab order, and Escape closes only the top

• A form with inline validation, a shake on invalid submit, a success state, and a confirm step before an unsaved form is discarded

• Roles: role="dialog" / role="alertdialog" with aria-modal, aria-labelledby, aria-haspopup="dialog" and aria-expanded on triggers, role="alert" on each field error

Quick Start

1. Add to your <head>:

Code snippet omitted: it ships with the download.

2. Add before the closing </body> tag:

Code snippet omitted: it ships with the download.

3. Copy the component markup from index.html into your page.

It is the block marked <!-- Component starts here -->: one [data-modal-root] wrapper holding [data-modal-backdrop] and one [data-modal] element per dialog. Nothing is found by id except the dialog a trigger names, so you can rename everything.

A trigger is any button, anywhere on the page:

Code snippet omitted: it ships with the download.

• data-modal-open is the id of the dialog it opens.
• data-modal-mode is optional; without it the dialog uses its own data-mode, defaulting to center.
• data-modal-dismiss on any button inside a dialog closes it (the close button and Cancel both use it).
• data-modal-inner wraps the dialog's contents so they can fade in behind the morph. Keep it.
• data-modal-autofocus names the control that should take focus on open; without it, the first focusable one does.

The form, the confirm dialog and the success panel are optional. A dialog with no [data-modal-form] in it never asks before closing.

The demo toolbar strip (the theme toggle and the placement control) and the short document the dialog opens over — the .stage-doc block in index.html and its rules at the bottom of assets/style.css — are demo furniture, there so the morph has something to launch from and the scroll lock is visible. They are not part of the component; leave them behind. thumbnail.html is a build-only capture frame and is not part of the component either.

Themes

One design at two sets of values, light (the default) and dark. Pick one by setting the attribute:

Code snippet omitted: it ships with the download.

Set it on <body> in the demo, or on the component's owning root in your page. Nothing else changes: same markup, same script, and the JavaScript never reads the theme name — where it needs a theme-dependent colour it reads the trigger's computed style at the moment of the morph. The demo's toggle and the ?variant=dark URL parameter only set that attribute.

Both blocks sit at the top of assets/style.css and define every value the component uses:

Token	What it paints
--ground, --ground-2	the page behind, and the demo toolbar strip
--raised, --hover	the dialog's surface, and the hover step above it
--ink, --ink-2, --ink-3	titles, body copy, labels and meta
--line, --line-strong	hairlines, and input and button borders
--accent, --accent-hover, --accent-ink, --accent-wash	the primary button, the trigger, the switch when on, the focus ring, the success mark
--danger	invalid field borders and their messages
--field-bg, --knob	input grounds, and the switch's knob
--backdrop, --shadow, --shadow-card	the scrim and the dialog's elevation
--radius-card, --radius-sm, --border-w, --font	the edge, and the face

To put it in your own brand, re-value that short list in both blocks — the accent is the only colour that carries any opinion, and it has one job: the primary action, the selected state and the focus ring. No selector override is ever needed.

How It Works

The morph, both ways. On open, the dialog is set to the trigger's exact box (top, left, width, height, plus the trigger's border radius and background), Flip.getState records that, the geometry is cleared so the dialog snaps to whatever its CSS placement is, and Flip.from animates the difference. Because the recorded box is cleared rather than kept, the same eight lines produce a centred dialog, a right-hand drawer or a bottom sheet — the placement is CSS and the morph is simply the difference. Closing captures the open state and applies the trigger's box instead, measured at that instant, which is why it returns to the right button after the page has scrolled.

Never scale: true. Flip can match two boxes by scaling, which is cheaper, but a container full of text scaled up from a 40px button is illegible for the whole tween. This one lets Flip tween width and height and fades the contents in behind them. For the same reason the dialog carries no min-height: it could not shrink back down to the trigger.

A stack, not a flag. Open dialogs live in an array, so Escape, the backdrop and the focus trap always address the last entry only. Opening one over another scales, dims and blurs the one underneath, sets aria-hidden and takes it out of pointer reach; closing brings it forward. The dirty-form confirm is nothing special — it is an ordinary dialog opened on top, morphing out of the close button it interrupted.

Closing hides for real. The dialog's hidden attribute is set in the morph's onComplete, and every property GSAP wrote is cleared there too. A faded-out overlay still covers the page and eats every click behind it, and a dialog left holding an inline width opens at the wrong size the second time.

Public API. The first instance is exposed for wiring:

Code snippet omitted: it ships with the download.

open() takes the trigger, not the dialog, because the trigger is what the morph flies out of.

Events. The root dispatches, all bubbling, with a detail object:

Event	When	detail
modal:open	a dialog is opening	id, mode, trigger, depth
modal:opened	its morph has finished	id, mode, trigger
modal:cancel	dismissed by Escape, the backdrop or a close button	id, reason
modal:close	any close, after modal:cancel	id, reason, depth
modal:submit	the form validated and was accepted	id
modal:invalid	a submit was rejected	id, fields

Code snippet omitted: it ships with the download.

Accessibility

Key	What it does
Enter / Space on a trigger	Opens its dialog and moves focus into it
Escape	Closes the top dialog only; focus returns to whatever opened it
Tab / Shift+Tab	Cycles within the top dialog and never leaves it
Enter on the form	Validates; invalid fields are marked, announced and the first one is focused

• Roles and state: each dialog is role="dialog" with aria-modal="true" and an aria-labelledby pointing at its title; the discard prompt is role="alertdialog". Triggers get aria-haspopup="dialog" and an aria-expanded that tracks the dialog. Field errors are role="alert" and referenced by aria-describedby, and each invalid field carries aria-invalid="true".
• Focus: moved to [data-modal-autofocus] (or the first focusable control) on open, trapped while open, and returned to the trigger on close. The trigger is hidden during the morph with opacity, never visibility, precisely so it is still focusable when focus comes back to it, and the dialog's contents fade in with opacity for the same reason: autoAlpha would set visibility: hidden on the frame focus moves in, and nothing inside a hidden box can take it.
• The page behind: while anything is open, overflow: hidden on <html> and <body> (on <body> alone it does nothing once <html> has any overflow of its own), plus position: fixed on <body> held at the offset the reader was at — overflow: hidden by itself clamps a scrolled page to the top, so the document would jump the moment the dialog opened. The scrollbar's width is added as padding so nothing shifts sideways, and the offset is scrolled back on unlock. It is released only when the last dialog closes.
• A dialog underneath is aria-hidden, pointer-events: none and outside the focus trap, so nothing behind the top dialog can be reached by pointer or keyboard.
• prefers-reduced-motion: reduce: the same states, the same code path, durations effectively zero. The dialog appears and disappears rather than morphing; nothing is disabled.
• Touch: the close button grows to 44px on coarse pointers, and a side drawer becomes a bottom sheet under 560px so it is reachable with a thumb.
• Without JavaScript the dialogs stay hidden and the page behind is untouched — nothing is pre-hidden by CSS that only JS can undo.

Customisation

• --dialog-w on a dialog sets its width in center and drawer mode (.fm-dialog--confirm uses it to make the discard prompt narrower).
• --backdrop is the scrim; --radius-card, --shadow-card and --border-w are the dialog's edge.
• Colours live in assets/style.css as custom properties per theme (the table above).
• Easing and durations are the Flip.from and gsap.to calls in assets/script.js: 0.6s power3.inOut in, 0.42s out, and one T multiplier that reduced motion sets to zero.
• Do not put a CSS transform on .fm-dialog or on a trigger — GSAP owns those, and a CSS transform underneath one is read as a pixel offset it never returns from. Do not give the dialog a min-height either, or the closing morph cannot shrink it back to the trigger.

Requirements

• GSAP 3.12+ plus the Flip plugin (the demo uses 3.15.0). Without Flip it degrades to a scale-and-fade and everything else still works.
• No build step, no framework
